| Nombor Bahagian | TCG070WVLPAANN-AN50-S |
| Jenama | Kyocera |
| Saiz | 7.0 |
| Permohonan | Industrial |
| Resolusi | 800×480 |
| Komposisi | a-Si TFT-LCD , LCM |
| Kecerahan | |
| CR | 1000:1 |
| Warna | 262K |
| Lampu latar | 2 |
| Antara muka | Parallel |
| jenama panel | Kyocera |
| saiz panel | 7.0" |
| resolusi | 800(RGB)×480, WVGA, 133PPI |
| kawasan paparan | 152.4(W)×91.44(H) mm |
| saiz garis besar | 165(W)×104.4(H) ×8.5(D) mm |
| kecerahan | 900 cd/m² (Typ.) |
| sudut pandangan | 80/80/60/80 (Typ.)(CR≥10) |
| pandangan terbaik pada | 12 o'clock |
| warna paparan | 262K 49% NTSC |
| kekerapan | - |
| berat panel | 195g (Typ.) |
| antara muka isyarat | Parallel RGB (1 ch, 6-bit) , 40 pins Connector |
| voltan masukan | 3.3V (Typ.) |
| persekitaran | Operating Temp.: -20 ~ 70 °C ; Storage Temp.: -30 ~ 80 °C |
| model panel | TCG070WVLPAANN-AN50-S |
| jenis panel | a-Si TFT-LCD , LCM |
| format piksel | RGB Vertical Stripe |
| pembukaan bezel | 154.4(W)×93.4(H) mm |
| permukaan | Antiglare |
| nisbah kontras | 1000:1 (Typ.) (TM) |
| mod paparan | TN, Normally White, Transmissive |
| masa tindak balas | 5/25 (Typ.)(Tr/Td) |
| jenis lampu | 2 strings WLED , 50K hours , Without Driver |
| skrin sentuh | Without |
| permohonan | Industrial |
