| Nombor Bahagian | T230XW01 V2 |
| Jenama | AUO |
| Saiz | 23.0 |
| Permohonan | LCTV |
| Resolusi | 1366×768 |
| Komposisi | LCM |
| Kecerahan | 500 |
| CR | 450:1 |
| Warna | 16.7M |
| Lampu latar | CCFL |
| Antara muka | LVDS |
| jenama panel | AUO |
| model panel | T230XW01 V2 1 Compatible model |
| jenis panel | a-Si TFT-LCD , LCM |
| saiz panel | 23.0 inch |
| resolusi | 1366(RGB)×768 , WXGA |
| mod paparan | TN, Normally White, Transmissive |
| kawasan aktif | 508.152×285.696 mm |
| garis besar | 546×318.3 mm |
| permukaan | Antiglare (Haze 26%), Hard coating (3H) |
| kecerahan | 500 cd/m² (Typ.) |
| nisbah kontras | 450:1 (Typ.) |
| warna paparan | 16.7M (8-bit) |
| masa tindak balas | 6/10 (Typ.)(Tr/Td) |
| sudut pandangan | 70/70/65/60 (Typ.)(CR≥10)(L/R/U/D) |
| kekerapan | 60Hz |
| jenis lampu | 8 pcsCCFLEmbedded (Inverter) |
| antara muka isyarat | LVDS (1 ch, 8-bit), 30 pins |
| voltan masukan | 12.0V (Typ.) |
| permohonan | LCTV |
