| Nombor Bahagian | LTM230HT02 |
| Jenama | Samsung |
| Saiz | 23.0 |
| Permohonan | DMPC |
| Resolusi | 1920×1080 |
| Komposisi | LCM |
| Kecerahan | 250 |
| CR | 1000:1 |
| Warna | 16.7M |
| Lampu latar | CCFL |
| Antara muka | LVDS |
| jenama panel | SAMSUNG |
| model panel | LTM230HT02 |
| jenis panel | a-Si TFT-LCD , LCM |
| saiz panel | 23.0 inch |
| resolusi | 1920(RGB)×1080 , FHD |
| mod paparan | TN, Normally White, Transmissive |
| kawasan aktif | 509.76×286.74 mm |
| garis besar | 534×311.7×12 mm |
| permukaan | Antiglare (Haze 25%), Hard coating (3H) |
| kecerahan | 250 cd/m² (Typ.) |
| nisbah kontras | 1000:1 (Typ.) |
| warna paparan | 16.7M (6-bit + Hi-FRC), CIE193172% |
| masa tindak balas | 5 (Typ.)(Tr+Td) |
| sudut pandangan | 80/80/80/80 (Typ.)(CR≥10)(L/R/U/D) |
| kekerapan | 60Hz |
| jenis lampu | 2 pcsCCFLWithout Driver |
| antara muka isyarat | LVDS (2 ch, 8-bit), 30 pins |
| voltan masukan | 5.0V (Typ.) |
| permohonan | DMPC |
| LTM230HL08 | Samsung | 23.0 | 1920×1080 |
| LTM230HP07 | Samsung | 23.0 | 1920×1080 |
| LTM230HT01 | Samsung | 23.0 | 1920×1080 |
| LTM230HT02 | Samsung | 23.0 | 1920×1080 |
| LTM230HT03 | Samsung | 23.0 | 1920×1080 |
| LTM230HT05 | Samsung | 23.0 | 1920×1080 |
| LTM230HT09 | Samsung | 23.0 | 1920×1080 |
| LTM230HT10 | Samsung | 23.0 | 1920×1080 |
| LTM230HU01 | Samsung | 23.0 | 1920×1080 |
| LTM230TT01 | Samsung | 23.0 | 2048×1152 |
| CLAA170EA07Q | CPT | 17.0 | 1280×1024 |
| HM185WX1-400 | BOE | 18.5 | 1366×768 |
| HR236WU3-301 | BOE | 23.6 | 1920×1080 |
| HT236F01-100 | BOE | 23.6 | 1920×1080 |
| LM220WE3-TLA1 | LG Display | 22.0 | 1680×1050 |
| LTM190E4-L02 | Samsung | 19.0 | 1280×1024 |
| M270HTN01.0 | AUO | 27.0 | 1920×1080 |
| NL160120BC27-14 | NLT | 21.3 | 1600×1200 |
| QD17EL07 Rev.09 | QDI | 17.0 | 1280×1024 |
| TM150XG-22L01A | SANYO | 15.0 | 1024×768 |
