| Nombor Bahagian | SP10Q010 |
| Jenama | KOE |
| Saiz | 3.8 |
| Permohonan | IA |
| Resolusi | 320×240 |
| Komposisi | LCM |
| Kecerahan | 110 |
| CR | 20:1 |
| Warna | Monochrome |
| Lampu latar | WLED |
| Antara muka | Parallel Data |
| jenama panel | KOE |
| model panel | SP10Q010 |
| jenis panel | FSTN-LCD , LCM |
| saiz panel | 3.8 inch |
| resolusi | 320×240 , QVGA |
| mod paparan | STN, Black/White (Negative), Transmissive |
| kawasan aktif | 76.79×57.59 mm |
| garis besar | 94.7×73.3×6 mm |
| permukaan | Glare (Haze 0%) |
| kecerahan | 110 cd/m² (Typ.) |
| nisbah kontras | 20:1 (Typ.) |
| warna paparan | Monochrome |
| masa tindak balas | 150/350 (Typ.)(Tr/Td) |
| sudut pandangan | 80 (Typ.)(CR≥2, Φ2-Φ1)(L/R/U/D) |
| kekerapan | 75Hz |
| jenis lampu | 1S6PWLEDWithout Driver |
| antara muka isyarat | Parallel Data (4-bit), 20 pins |
| voltan masukan | 3.3V (Typ.) |
| permohonan | IA |
