| Nombor Bahagian | LQ049B5DG04 |
| Jenama | SHARP |
| Saiz | 4.9 |
| Permohonan | CNS |
| Resolusi | 320×96 |
| Komposisi | LCM |
| Kecerahan | 350 |
| CR | 60:1 |
| Warna | 262K |
| Lampu latar | CCFL |
| Antara muka | TTL |
| jenama panel | SHARP |
| model panel | LQ049B5DG04 |
| jenis panel | a-Si TFT-LCD , LCM |
| saiz panel | 4.9 inch |
| resolusi | 320(RGB)×96 |
| mod paparan | TN, Normally White, Transmissive |
| kawasan aktif | 120×36 mm |
| garis besar | 142×53.5 mm |
| permukaan | Antiglare |
| kecerahan | 350 cd/m² (Typ.) |
| nisbah kontras | 60:1 (Min.) |
| warna paparan | 262K (6-bit) |
| masa tindak balas | 30/50 (Typ.)(Tr/Td) |
| sudut pandangan | 65/65/40/65 (Typ.)(CR≥10)(L/R/U/D) |
| jenis lampu | 1 pcsCCFLWithout Driver |
| antara muka isyarat | Parallel RGB (1 ch, 6-bit), 30 pins |
| voltan masukan | 5.0/10.0/-10.0V (Typ.)(VSH/VGH/VGL) |
| rohs: | |
| permohonan | CNS |
