| Nombor Bahagian | PT236AT02-4 |
| Jenama | HKC |
| Saiz | 23.6 |
| Permohonan | TV Sets |
| Resolusi | 1366×768 |
| Komposisi | CELL , a-Si TFT-LC |
| Kecerahan | |
| CR | 3000:1 |
| Warna | 16.7M |
| Lampu latar | No |
| Antara muka | LVDS |
| pengilang | HKC |
| saiz skrin | 23.6 inch |
| nombor piksel | 1366(RGB)×768 (WXGA) 66PPI |
| kawasan aktif (mm) | 521.471 × 293.184 (H×V) |
| kawasan bezel (mm) | - |
| kecerahan | 0 cd/m² |
| sudut pandangan | 89/89/89/89 (Typ.)(CR≥10) |
| pandangan yang baik di | Symmetry |
| ketebalan kaca | 0.50+0.50 mm |
| kedalaman warna | 16.7M 73% NTSC |
| jisim | 500g (Typ.) |
| kadar segar semula | 60Hz |
| senarai ic pemandu | Built-in COF 2 source + 2 gate chips |
| jenis isyarat | LVDS (1 ch, 8-bit) , 30 pins Connector |
| bekalan voltan | 12.0V (Typ.) |
| maks. penilaian | Storage Temp.: -20 ~ 60 °C Operating Temp.: 0 ~ 50 °C |
| nama model | PT236AT02-4 |
| jenis skrin | CELL , a-Si TFT-LCD |
| susunan | RGB Vertical Stripe |
| garis besar (mm) | 535.471 × 306.404 × 1.4 (H×V×D) |
| rawatan | Antiglare, Hard coating (3H) |
| nisbah kontras | 3000 : 1 (Typ.) (TM) |
| tindak balas | 9.5 (Typ.)(G to G) ms |
| mod kerja | FSA, Normally Black, Transmissive |
| ketransmisian | 5.8% (Typ.)(with Polarizer) |
| lampu latar | No B/L |
| digunakan untuk | TV Sets |
| skrin sentuh | Without |
