| Nombor Bahagian | A025DN01 V9 |
| Jenama | AUO |
| Saiz | 2.5 |
| Permohonan | DSC |
| Resolusi | 320×240 |
| Komposisi | LCM |
| Kecerahan | 250 |
| CR | 300:1 |
| Warna | 16.7M |
| Lampu latar | WLED |
| Antara muka | Serial RGB |
| jenama panel | AUO |
| model panel | A025DN01 V9 |
| jenis panel | a-Si TFT-LCD , LCM |
| saiz panel | 2.5 inch |
| resolusi | 320(RGB)×240 , QVGA |
| mod paparan | TN, Normally White, Transmissive |
| kawasan aktif | 49.92×37.44 mm |
| garis besar | 59.63×43.7×2.9 mm |
| permukaan | Hard coating |
| kecerahan | 250 cd/m² (Typ.) |
| nisbah kontras | 300:1 (Typ.) |
| warna paparan | 16.7M (8-bit) |
| masa tindak balas | 15/20 (Typ.)(Tr/Td) |
| sudut pandangan | 45/45/20/40 (Typ.)(CR≥10)(L/R/U/D) |
| kekerapan | 60Hz |
| jenis lampu | 1 pcsWLED |
| antara muka isyarat | Serial RGB (8-bit) + SPI, CCIR601/656, 39 pins |
| voltan masukan | 3.3/15/-10V (VDD/VGH/VGL) |
| permohonan | DSC |
