| Nombor Bahagian | CLAA070LH01AW |
| Jenama | CPT |
| Saiz | 7.0 |
| Permohonan | CNS |
| Resolusi | 800×480 |
| Komposisi | LCM |
| Kecerahan | 600 |
| CR | 800:1 |
| Warna | 262K |
| Lampu latar | WLED |
| Antara muka | TTL |
| jenama panel | CPT |
| model panel | CLAA070LH01AW |
| jenis panel | a-Si TFT-LCD , LCM |
| saiz panel | 7.0 inch |
| resolusi | 800(RGB)×480 , WVGA |
| mod paparan | TN, Normally White, Transmissive |
| kawasan aktif | 152.4×91.44 mm |
| garis besar | 165×104×7.55 mm |
| permukaan | Antiglare, Reflection 4.0% (Typ.) |
| kecerahan | 600 cd/m² (Typ.) |
| nisbah kontras | 800:1 (Typ.) |
| warna paparan | 262K (6-bit), CIE193150% |
| masa tindak balas | 40 (Max.)(Tr+Td) |
| sudut pandangan | 55/55/60/30 (Min.)(CR≥10)(L/R/U/D) |
| kekerapan | 60Hz |
| jenis lampu | 7S2PWLEDWithout Driver |
| antara muka isyarat | TTL (1 ch, 6-bit), 60 pins |
| voltan masukan | 3.3/13.0/18.0/-6.0V (Typ.)(DVDD/AVDD/VGH/VGL) |
| permohonan | CNS |
