| Nombor Bahagian | P101DCZ-3Z0 |
| Jenama | Innolux |
| Saiz | 10.1 |
| Permohonan | Pad & Tablet |
| Resolusi | 800×1280 |
| Komposisi | CELL , a-Si TFT-LC |
| Kecerahan | |
| CR | 800:1 |
| Warna | 16.7M |
| Lampu latar | No |
| Antara muka | MIPI |
| pengilang | Innolux |
| saiz skrin | 10.1 inch |
| nombor piksel | 800(RGB)×1280 (WXGA) 150PPI |
| kawasan aktif (mm) | 135.36 × 216.576 (H×V) |
| kawasan bezel (mm) | - |
| kecerahan | 0 cd/m² |
| sudut pandangan | 85/85/85/85 (Typ.)(CR≥10) |
| pandangan yang baik di | Symmetry |
| ketebalan kaca | - |
| kedalaman warna | 16.7M 59% NTSC |
| jisim | - |
| kadar segar semula | 60Hz |
| jenis isyarat | MIPI (4 data lanes) , 40 pins Connector |
| bekalan voltan | 3.3/5.8/-5.8V (Typ.)(VDDIN/AVDD/AVEE) |
| maks. penilaian | Storage Temp.: -20 ~ 60 °C Operating Temp.: 0 ~ 50 °C |
| nama model | P101DCZ-3Z0 |
| jenis skrin | CELL , a-Si TFT-LCD |
| susunan | RGB Vertical Stripe |
| garis besar (mm) | - |
| rawatan | Clear, Hard coating (3H) |
| nisbah kontras | 800 : 1 (Typ.) (TM) |
| tindak balas | 25 (Typ.)(Tr+Td) ms |
| mod kerja | AAS, Normally Black, Transmissive |
| ketransmisian | 4.73% (Typ.)(with Polarizer) |
| lampu latar | No B/L |
| digunakan untuk | Pad & Tablet |
| skrin sentuh | Without |
