NVK16BSC001G-C-0000

NVK16BSC001G-C-0000
NVK16BSC001G-C-0000
NVK16BSC001G-C-0000
NVK16BSC001G-C-0000 thumb NVK16BSC001G-C-0000 thumb NVK16BSC001G-C-0000 thumb
Jenama
Neoview Kolon
Saiz
1.7
Permohonan
SB
Resolusi
80×168
Komposisi
OLED
Kecerahan
250
CR
Warna
262K
Lampu latar
self
Antara muka
CPU
In Stock
19654
Spesifikasi

Nombor Bahagian NVK16BSC001G-C-0000
JenamaNeoview Kolon
Saiz1.7
PermohonanSB
Resolusi80×168
KomposisiOLED
Kecerahan250
CR
Warna262K
Lampu latarself
Antara mukaCPU
jenama panelNeoview Kolon
model panelNVK16BSC001G-C-0000
jenis panel PM-OLED , OLED
saiz panel1.7 inch
resolusi80(RGB)×168
kawasan aktif18.446×38.782 mm
garis besar26×50 mm
permukaan
kecerahan250 cd/m² (Typ.)
nisbah kontras
warna paparan262K (6-bit)
sudut pandangan
ic pemanduBuilt-in SSD1352
antara muka isyarat8-bit 8080 parallel
voltan masukan2.8/1.8/16V (Typ.)(VCI/VCCIO/VCC)
permohonanSB
