| Nombor Bahagian | M236HVR01.0 CELL |
| Jenama | AUO |
| Saiz | 23.6 |
| Permohonan | Desktop Monitor Gami |
| Resolusi | 1920×1080 |
| Komposisi | a-Si TFT-LCD , CELL |
| Kecerahan | |
| CR | 3000:1 |
| Warna | 16.7M |
| Lampu latar | No |
| Antara muka | |
| jenama panel | AUO |
| saiz panel | 23.6" |
| resolusi | 1920(RGB)×1080, FHD, 93PPI |
| kawasan paparan | 521.395(W)×293.285(H) mm |
| saiz garis besar | 532.995(W)×305.185(H) ×1.11(D) mm |
| kecerahan | 0 cd/m² |
| sudut pandangan | 89/89/89/89 (Typ.)(CR≥10) |
| pandangan terbaik pada | Symmetry |
| kedalaman kaca | 0.40+0.40 mm |
| warna paparan | 16.7M 69% NTSC |
| kekerapan | 165Hz |
| berat badan | 530g (Typ.) |
| model panel | M236HVR01.0 CELL |
| jenis panel | a-Si TFT-LCD , CELL |
| format piksel | RGB Vertical Stripe |
| pembukaan bezel | - |
| permukaan | Antiglare (Haze 40%), Hard coating (3H) |
| nisbah kontras | 3000:1 (Typ.) (TM) |
| mod paparan | VA, Normally Black, Transmissive |
| masa tindak balas | 20 (Typ.)(G to G) |
| ketransmisian | 3.22% (Typ.)(with Polarizer) |
| jenis lampu | No B/L |
| skrin sentuh | Without |
| permohonan | Desktop Monitor Gaming |
| HR236WU1-100 | BOE | 23.6 | 1920×1080 |
| HR236WU1-300 | BOE | 23.6 | 1920×1080 |
| HR236WU3-301 | BOE | 23.6 | 1920×1080 |
| M236H3-L05 | Innolux | 23.6 | 1920×1080 |
| M236H3-LA2 | Innolux | 23.6 | 1920×1080 |
| M236HGK-L30 | Innolux | 23.6 | 1920×1080 |
| MV236FHB-N10 | BOE | 23.6 | 1920×1080 |
| P236MWF1 R0 | IVO | 23.6 | 1920×1080 |
| V236BJ1-P01 | Innolux | 23.6 | 1366×768 |
| V236BJ1-P02 | Innolux | 23.6 | 1366×768 |
