| Nombor Bahagian | M230HCJ-L3N Rev.C1 |
| Jenama | Innolux |
| Saiz | 23.0 |
| Permohonan | Desktop Monitor |
| Resolusi | 1920×1080 |
| Komposisi | a-Si TFT-LCD, LCM |
| Kecerahan | |
| CR | 1000:1 |
| Warna | 16.7M |
| Lampu latar | 4 |
| Antara muka | LVDS |
| jenama panel | Innolux |
| model panel | M230HCJ-L3N Rev.C1 |
| saiz panel | 23.0" |
| jenis panel | a-Si TFT-LCD, LCM |
| resolusi | 1920(RGB)×1080, FHD, 95PPI |
| format piksel | RGB Vertical Stripe |
| kawasan paparan | 509.184(W)×286.416(H) mm |
| pembukaan bezel | 512.38(W)×289.62(H) mm |
| saiz garis besar | 522.38(W)×305.62(H) mm |
| permukaan | Antiglare (Haze 25%), Hard coating (3H) |
| kecerahan | 250 cd/m² (Typ.) |
| nisbah kontras | 1000:1 (Typ.) (TM) |
| sudut pandangan | 89/89/89/89 (Typ.)(CR≥10) |
| mod paparan | AAS, Normally Black, Transmissive |
| pandangan terbaik pada | Symmetry |
| masa tindak balas | 8/7 (Typ.)(Tr/Td) |
| warna paparan | 16.7M 72% NTSC |
| jenis lampu | 4 strings WLED , Without Driver |
| kekerapan | 60Hz |
| skrin sentuh | Without |
| berat panel | 1.96/2.06/2.23Kgs (Min./Typ./Max.) |
| permohonan | Desktop Monitor |
| antara muka isyarat | LVDS (2 ch, 8-bit) , 30 pins Connector |
| voltan masukan | 5.0V (Typ.) |
| persekitaran | Operating Temp.: 0 ~ 50 °C ; Storage Temp.: -20 ~ 60 °C |
