| Nombor Bahagian | LC230WX3-SLA1 |
| Jenama | LG Display |
| Saiz | 23.0 |
| Permohonan | LCTV |
| Resolusi | 1366×768 |
| Komposisi | LCM |
| Kecerahan | 450 |
| CR | 800:1 |
| Warna | 16.7M |
| Lampu latar | CCFL |
| Antara muka | LVDS |
| jenama panel | LG.Philips LCD |
| model panel | LC230WX3-SLA1 |
| jenis panel | a-Si TFT-LCD , LCM |
| saiz panel | 23.0 inch |
| resolusi | 1366(RGB)×768 , WXGA |
| mod paparan | S-IPS, Normally Black, Transmissive |
| kawasan aktif | 508.152×285.696 mm |
| garis besar | 546×318.3 mm |
| permukaan | Antiglare, Hard coating (3H) |
| kecerahan | 450 cd/m² (Typ.) |
| nisbah kontras | 800:1 (Typ.) |
| warna paparan | 16.7M (8-bit) |
| masa tindak balas | 9/9 (Typ.)(Tr/Td) |
| sudut pandangan | 89/89/89/89 (Typ.)(CR≥10)(L/R/U/D) |
| kekerapan | 60Hz |
| jenis lampu | 6 pcsCCFLEmbedded (Inverter) |
| antara muka isyarat | LVDS (1 ch, 8-bit), 30 pins |
| voltan masukan | 12.0V (Typ.) |
| rohs: | |
| permohonan | LCTV |
| LC230W01-A2 | LG Display | 23.0 | 1280×768 |
| LC230WX3-SLA1 | LG Display | 23.0 | 1366×768 |
| LM230WF3-SLK1 | LG Display | 23.0 | 1920×1080 |
| LM230WF5-TLA3 | LG Display | 23.0 | 1920×1080 |
| LM230WF5-TLD1 | LG Display | 23.0 | 1920×1080 |
| LM230WF5-TLF4 | LG Display | 23.0 | 1920×1080 |
| LTM230HP07 | Samsung | 23.0 | 1920×1080 |
| LTM230HT09 | Samsung | 23.0 | 1920×1080 |
| LTM230HT10 | Samsung | 23.0 | 1920×1080 |
| LTM230HU01 | Samsung | 23.0 | 1920×1080 |
| LC216EXN-SDA2 | LG Display | 21.6 | 1366×768 |
| LC320WUN-SCB1 | LG Display | 31.5 | 1920×1080 |
| LC420EUN-SEM1 | LG Display | 42 | 1920×1080 |
| LC470WUN-SCA1 | LG Display | 47 | 1920×1080 |
| LC550EUH-RDA2 | LG Display | 55 | 1920×1080 |
| LK600D3LA3K | SHARP | 60 | 1920×1080 |
| LSC550FJ06-W01 | Samsung | 55 | 3840×2160 |
| LTF460HF08 | Samsung | 46 | 1920×1080 |
| T460HB01 V0 | AUO | 46 | 1920×1080 |
| T470HVN01.1 | AUO | 47 | 1920×1080 |
