| Nombor Bahagian | M101GWWF R0 |
| Jenama | IVO |
| Saiz | 10.1 |
| Permohonan | Laptop |
| Resolusi | 1280×800 |
| Komposisi | a-Si TFT-LCD, LCM |
| Kecerahan | |
| CR | 800:1 |
| Warna | 16.7M |
| Lampu latar | WLED |
| Antara muka | LVDS |
| jenama | IVO |
| model | M101GWWF R0 |
| saiz pepenjuru | 10.1 inch |
| menaip | a-Si TFT-LCD, LCM |
| format piksel | 1280(RGB)×800 [WXGA] 149PPI |
| konfigurasi | RGB Vertical Stripe |
| kawasan aktif | 216.96(H)×135.6(V) mm |
| garis besar malap. | 229.46(H)×149.1(V) ×4.56(D) mm |
| kawasan bezel | - |
| rawatan | Glare (Haze 0%), Hard coating (3H) |
| kecerahan | 350 cd/m² (Typ.) |
| nisbah kontras | 800:1 (Typ.) (TM) |
| arah pandang | Symmetry |
| masa tindak balas | 25 (Typ.)(Tr+Td) |
| sudut pandangan | 85/85/85/85 (Typ.)(CR≥10) |
| mod operasi | IPS, Normally Black, Transmissive |
| warna sokongan | 16.7M |
| sumber cahaya | WLED , 25K hours , With LED Driver |
| gaya bentuk | Slim (PCBA Bent, T≤3.0mm) |
| direka untuk | Laptop |
| kadar bingkai | 60Hz |
| panel sentuh | Without |
| jenis antara muka | LVDS (1 ch, 8-bit) , 40 pins Connector |
| bekalan kuasa | 3.3V (Typ.) |
| persekitaran | Operating Temperature: -20 ~ 70 °C ; Storage Temperature: -30 ~ 80 °C |
