| Nombor Bahagian | LTM230HL10-C01 |
| Jenama | SAMSUNG |
| Saiz | 23.0 |
| Permohonan | Desktop Monitor |
| Resolusi | 1920×1080 |
| Komposisi | a-Si TFT-LCD , LCM |
| Kecerahan | |
| CR | 1000:1 |
| Warna | 16.7M |
| Lampu latar | WLED |
| Antara muka | |
| jenama panel | SAMSUNG |
| saiz panel | 23.0" |
| resolusi | 1920(RGB)×1080, FHD, 95PPI |
| kawasan paparan | 509.184(W)×286.416(H) mm |
| saiz garis besar | 522.38(W)×305.62(H) ×12.6(D) mm |
| kecerahan | 250 cd/m² (Typ.) |
| sudut pandangan | 89/89/89/89 (Typ.)(CR≥10) |
| pandangan terbaik pada | Symmetry |
| warna paparan | 16.7M 72% NTSC |
| kekerapan | 60Hz |
| berat badan | 2.38Kgs (Max.) |
| model panel | LTM230HL10-C01 |
| jenis panel | a-Si TFT-LCD , LCM |
| format piksel | RGB Vertical Stripe |
| pembukaan bezel | 512.384(W)×289.616(H) mm |
| permukaan | - |
| nisbah kontras | 1000:1 (Typ.) (TM) |
| mod paparan | PLS, Normally Black, Transmissive |
| masa tindak balas | 14 (Typ.)(G to G) |
| jenis lampu | WLED , 40K hours , Without Driver |
| skrin sentuh | Without |
| permohonan | Desktop Monitor |
