| Nombor Bahagian | LTM170E8-L21 |
| Jenama | Samsung |
| Saiz | 17.0 |
| Permohonan | DMPC |
| Resolusi | 1280×1024 |
| Komposisi | LCM |
| Kecerahan | 300 |
| CR | 1500:1 |
| Warna | 16.7M |
| Lampu latar | CCFL |
| Antara muka | LVDS |
| jenama panel | SAMSUNG |
| model panel | LTM170E8-L21 3 Compatible model |
| jenis panel | a-Si TFT-LCD , LCM |
| saiz panel | 17.0 inch |
| resolusi | 1280(RGB)×1024 , SXGA |
| mod paparan | PVA, Normally Black, Transmissive |
| kawasan aktif | 337.92×270.336 mm |
| garis besar | 354.9×290.3×13.3 mm |
| permukaan | Antiglare (Haze 44%), Hard coating (3H) |
| kecerahan | 300 cd/m² (Typ.) |
| nisbah kontras | 1500:1 (Typ.) |
| warna paparan | 16.7M (8-bit) |
| masa tindak balas | 15/10 (Typ.)(Tr/Td) |
| sudut pandangan | 89/89/89/89 (Typ.)(CR≥10)(L/R/U/D) |
| kekerapan | 60Hz |
| jenis lampu | 4 pcsCCFLWithout Driver |
| antara muka isyarat | LVDS (2 ch, 8-bit), 30 pins |
| voltan masukan | 5.0V (Typ.) |
| permohonan | DMPC |
| LTM170E4-P01 | Samsung | 17.0 | 1280×1024 |
| LTM170E6-L03 | Samsung | 17.0 | 1280×1024 |
| LTM170E6-L04 | Samsung | 17.0 | 1280×1024 |
| LTM170E8-L21 | Samsung | 17.0 | 1280×1024 |
| LTM170EI-A01 | Samsung | 17.0 | 1280×1024 |
| LTM170EU-A01 | Samsung | 17.0 | 1280×1024 |
| LTM170EU-L01 | Samsung | 17.0 | 1280×1024 |
| LTM170EU-L11 | Samsung | 17.0 | 1280×1024 |
| LTM170EX-L31 | Samsung | 17.0 | 1280×1024 |
| LTM170W1-L01 | Samsung | 17.0 | 1280×768 |
| CLAA185WA04 | CPT | 18.5 | 1366×768 |
| FLC38XGC6V-06 | Fujitsu | 15.0 | 1024×768 |
| HR215WU1-210 | BOE | 21.5 | 1920×1080 |
| LM215WF1-TLB1 | LG Display | 21.5 | 1920×1080 |
| LM260WU2-SLA2 | LG Display | 25.5 | 1920×1200 |
| LM270WQ1-SDB3 | LG Display | 27.0 | 2560×1440 |
| LTM201M1-L01 | Samsung | 20.1 | 1680×1050 |
| LTM213U6-L01 | Samsung | 21.3 | 1600×1200 |
| M185XW01 VF | AUO | 18.5 | 1366×768 |
| SVA150XG04TB | SVA-NEC | 15.0 | 1024×768 |
