AUO M185XW01 VF lembaran data, spesifikasi, stok, aplikasi www.looklcd-my.com
LookLCD LookLCD


M185XW01 VF

M185XW01 VF
M185XW01 VF
M185XW01 VF
M185XW01 VF thumb M185XW01 VF thumb M185XW01 VF thumb
Jenama
AUO
Saiz
18.5
Permohonan
DMPC
Resolusi
1366×768
Komposisi
LCM
Kecerahan
250
CR
1000:1
Warna
16.7M
Lampu latar
WLED
Antara muka
LVDS
In Stock
938
Spesifikasi

Nombor Bahagian M185XW01 VF
JenamaAUO
Saiz18.5
PermohonanDMPC
Resolusi1366×768
KomposisiLCM
Kecerahan250
CR1000:1
Warna16.7M
Lampu latarWLED
Antara mukaLVDS
jenama panelAUO
model panelM185XW01 VF
jenis panel a-Si TFT-LCD , LCM
saiz panel18.5 inch
resolusi1366(RGB)×768 , WXGA
mod paparanTN, Normally White, Transmissive
kawasan aktif409.8×230.4 mm
garis besar430.4×254.6×10.4 mm
permukaanAntiglare, Hard coating (3H)
kecerahan250 cd/m² (Typ.)
nisbah kontras1000:1 (Typ.)
warna paparan16.7M (6-bit + Hi-FRC), CIE193172%
masa tindak balas3.6/1.4 (Typ.)(Tr/Td)
sudut pandangan85/85/80/80 (Typ.)(CR≥10)(L/R/U/D)
kekerapan60Hz
jenis lampu10S4PWLEDWithout Driver
antara muka isyaratLVDS (1 ch, 8-bit), 30 pins
voltan masukan5.0V (Typ.)
permohonanDMPC
Model Keluarga
M185XTN01.0 AUO 18.5 1366×768
M185XTN01.2 AUO 18.5 1366×768
M185XTN01.3 AUO 18.5 1366×768
M185XW01 V1 AUO 18.5 1366×768
M185XW01 V2 AUO 18.5 1366×768
M185XW01 V3 AUO 18.5 1366×768
M185XW01 V4 AUO 18.5 1366×768
M185XW01 V5 AUO 18.5 1366×768
M185XW01 V6 AUO 18.5 1366×768
M185XW01 V8 AUO 18.5 1366×768
