LTI460HM02

LTI460HM02
LTI460HM02
LTI460HM02
LTI460HM02 thumb LTI460HM02 thumb LTI460HM02 thumb
Jenama
Samsung
Saiz
46
Permohonan
PID
Resolusi
1920×1080
Komposisi
LCM
Kecerahan
700
CR
3500:1
Warna
16.7M
Lampu latar
CCFL
Antara muka
LVDS
In Stock
2561
Spesifikasi

Nombor Bahagian LTI460HM02
JenamaSamsung
Saiz46
PermohonanPID
Resolusi1920×1080
KomposisiLCM
Kecerahan700
CR3500:1
Warna16.7M
Lampu latarCCFL
Antara mukaLVDS
jenama panelSAMSUNG
model panelLTI460HM02
jenis panel a-Si TFT-LCD , LCM
saiz panel46 inch
resolusi1920(RGB)×1080 , FHD
mod paparanS-PVA, Normally Black, Transmissive
kawasan aktif1018.08×572.67 mm
garis besar1047.4×600.6×66.1 mm, Videowall Seam 29.3 mm
permukaanAntiglare (Haze 44%), Hard coating (3H)
kecerahan700 cd/m² (Typ.)
nisbah kontras3500:1 (Typ.)
warna paparan16.7M (8-bit), CIE193172%
masa tindak balas8 (Typ.)(G to G)
sudut pandangan89/89/89/89 (Typ.)(CR≥10)(L/R/U/D)
kekerapan60Hz
jenis lampu12 pcsCCFLEmbedded (Inverter)
antara muka isyaratLVDS (2 ch, 8-bit), 51 pins
voltan masukan12.0V (Typ.)
permohonanPID
Model Keluarga
LTI460AA01-001 Samsung 46 1366×768
LTI460AA03 Samsung 46 1366×768
LTI460AA05 Samsung 46 1366×768
LTI460AP01 Samsung 46 1366×768
LTI460HA01 Samsung 46 1920×1080
LTI460HA03 Samsung 46 1920×1080
LTI460HM01 Samsung 46 1920×1080
LTI460HN07 Samsung 46 1920×1080
LTI460HN08 Samsung 46 1920×1080
LTI460HN09 Samsung 46 1920×1080
