| Nombor Bahagian | LD470DUE-SFR1 |
| Jenama | LG Display |
| Saiz | 47 |
| Permohonan | PID |
| Resolusi | 1920×1080 |
| Komposisi | LCM |
| Kecerahan | 400 |
| CR | 1200:1 |
| Warna | 16.7M |
| Lampu latar | WLED |
| Antara muka | LVDS |
| jenama panel | LG Display |
| model panel | LD470DUE-SFR1 |
| jenis panel | a-Si TFT-LCD , LCM |
| saiz panel | 47 inch |
| resolusi | 1920(RGB)×1080 , FHD |
| mod paparan | IPS, Normally Black, Transmissive |
| kawasan aktif | 1039.68×584.82 mm |
| garis besar | 1067.6×617.4 mm |
| permukaan | Antiglare (Haze 1%), Hard coating (3H) |
| kecerahan | 400 cd/m² (Typ.) |
| nisbah kontras | 1200:1 (Typ.) |
| warna paparan | 16.7M (8-bit), CIE193168% |
| masa tindak balas | |
| sudut pandangan | 89/89/89/89 (Min.)(CR≥10)(L/R/U/D) |
| kekerapan | 60Hz |
| jenis lampu | WLEDWithout Driver |
| antara muka isyarat | LVDS (2 ch, 8-bit), 51 pins |
| voltan masukan | 12.0V (Typ.) |
| permohonan | PID |
