| Nombor Bahagian | LTI570HD01 |
| Jenama | Samsung |
| Saiz | 57 |
| Permohonan | PID |
| Resolusi | 1920×1080 |
| Komposisi | LCM |
| Kecerahan | |
| CR | |
| Warna | 16.7M |
| Lampu latar | CCFL |
| Antara muka | LVDS |
| jenama panel | SAMSUNG |
| model panel | LTI570HD01 |
| jenis panel | a-Si TFT-LCD , LCM |
| saiz panel | 57 inch |
| resolusi | 1920(RGB)×1080 , FHD |
| mod paparan | PVA, Normally Black, Transmissive |
| permukaan | |
| kecerahan | |
| nisbah kontras | |
| warna paparan | 16.7M (8-bit) |
| masa tindak balas | |
| sudut pandangan | |
| kekerapan | 60Hz |
| jenis lampu | 36 pcsCCFLEmbedded (Balance board) |
| antara muka isyarat | LVDS (2 ch, 8-bit), 51 pins |
| voltan masukan | 12.0V (Typ.) |
| permohonan | PID |
| LTA570HH-LH2 | Samsung | 57 | 1920×1080 |
| LTI570HD01 | Samsung | 57 | 1920×1080 |
| BRS550H2 | BERISE | 55 | 1920×1080 |
| LD420EUP-SEA1 | LG Display | 42 | 1920×1080 |
| LD470WUB-SCA1 | LG Display | 47 | 1920×1080 |
| LTI320AA02 | Samsung | 31.5 | 1366×768 |
| LTI370LN02 | Samsung | 37 | 1920×540 |
| LTI400HA04 | Samsung | 40 | 1920×1080 |
| LTI400HA08-V | Samsung | 40 | 1920×1080 |
| LTI460AP01 | Samsung | 46 | 1366×768 |
| LTI460HN08 | Samsung | 46 | 1920×1080 |
| RX320HD01-DC15 | ROGIN | 31.5 | 1920×1080 |
