Samsung LTA400HM21-W lembaran data, spesifikasi, stok, aplikasi www.looklcd-my.com
LookLCD LookLCD


LTA400HM21-W

LTA400HM21-W
LTA400HM21-W
LTA400HM21-W thumb LTA400HM21-W thumb
Jenama
Samsung
Saiz
40
Permohonan
LCTV
Resolusi
1920×1080
Komposisi
LCM
Kecerahan
320
CR
4000:1
Warna
16.7M
Lampu latar
WLED
Antara muka
LVDS
In Stock
8785
Spesifikasi

Nombor Bahagian LTA400HM21-W
JenamaSamsung
Saiz40
PermohonanLCTV
Resolusi1920×1080
KomposisiLCM
Kecerahan320
CR4000:1
Warna16.7M
Lampu latarWLED
Antara mukaLVDS
jenama panelSAMSUNG
model panelLTA400HM21-W
jenis panel a-Si TFT-LCD , LCM
saiz panel40 inch
resolusi1920×1080(RGB) , FHD
mod paparanSPVA, Normally Black, Transmissive
kawasan aktif885.6×498.15 mm
garis besar921.7×536.3×32.5 mm
permukaanAntiglare
kecerahan320 cd/m² (Typ.)
nisbah kontras4000:1 (Typ.)
warna paparan16.7M (8-bit), CIE193170%
masa tindak balas8 (Typ.)(G to G)
sudut pandangan89/89/89/89 (Typ.)(CR≥10)(L/R/U/D)
kekerapan60Hz
jenis lampuWLEDEmbedded (LED Driver)
antara muka isyaratLVDS (2 ch, 8-bit), 51 pins
voltan masukan12.0V (Typ.)
permohonanLCTV
Model Keluarga
LTA400HA11 Samsung 40 1920×1080
LTA400HF02 Samsung 40 1920×1080
LTA400HF23 Samsung 40 1920×1080
LTA400HH-L02 Samsung 40 1920×1080
LTA400HL10 Samsung 40 1920×1080
LTA400HM07 Samsung 40 1920×1080
LTA400HM13 Samsung 40 1920×1080
LTA400HM1C-001 Samsung 40 1920×1080
LTA400HM23 Samsung 40 1920×1080
LTA400WT-L09 Samsung 40 1366×768
