Samsung LTA400HM1C-001 lembaran data, spesifikasi, stok, aplikasi www.looklcd-my.com

LTA400HM1C-001


Jenama
Samsung
Saiz
40
Permohonan
LCTV
Resolusi
1920×1080
Komposisi
LCM
Kecerahan
500
CR
2000:1
Warna
1.07B
Lampu latar
CCFL
Antara muka
LVDS
In Stock
10129
Spesifikasi

Nombor Bahagian LTA400HM1C-001
JenamaSamsung
Saiz40
PermohonanLCTV
Resolusi1920×1080
KomposisiLCM
Kecerahan500
CR2000:1
Warna1.07B
Lampu latarCCFL
Antara mukaLVDS
jenama panelSAMSUNG
model panelLTA400HM1C-001
jenis panel a-Si TFT-LCD , LCM
saiz panel40 inch
resolusi1920(RGB)×1080 , FHD
mod paparanS-PVA, Normally Black, Transmissive
kawasan aktif885.6×498.15 mm
garis besar911.7×524.2 mm
permukaanAntiglare (Haze 5%), Hard coating (3H)
kecerahan500 cd/m² (Typ.)
nisbah kontras2000:1 (Typ.)
warna paparan1.07B (10-bit), CIE193190%
masa tindak balas6 (Typ.)(G to G)); 8 (Typ.)(MPRT)
sudut pandangan89/89/89/89 (Typ.)(CR≥10)(L/R/U/D)
kekerapan60Hz
jenis lampu22 pcsCCFLEmbedded (Inverter)
antara muka isyaratLVDS (2 ch, 10-bit), 51 pins
voltan masukan12.0V (Typ.)
permohonanLCTV
