| Nombor Bahagian | HT260WX2-101 |
| Jenama | BOE |
| Saiz | 26.0 |
| Permohonan | LCTV |
| Resolusi | 1366×768 |
| Komposisi | CELL |
| Kecerahan | 0 |
| CR | 800:1 |
| Warna | 16.7M |
| Lampu latar | No B/L |
| Antara muka | LVDS |
| jenama panel | BOE |
| model panel | HT260WX2-101 |
| jenis panel | a-Si TFT-LCD , CELL |
| saiz panel | 26.0 inch |
| resolusi | 1366(RGB)×768 , WXGA |
| mod paparan | TN, Normally White, Transmissive |
| kawasan aktif | 575.769×323.712 mm |
| garis besar | 592×339.8 mm |
| permukaan | Antiglare (Haze 25%), Hard coating (3H) |
| kedalaman kaca | 0.70+0.70 mm |
| ketransmisian | 7.05% (Typ.)(with Polarizer) |
| nisbah kontras | 800:1 (Typ.) |
| warna paparan | 16.7M (6-bit + Hi-FRC), CIE193172% |
| masa tindak balas | 5 (Typ.)(G to G) |
| sudut pandangan | 80/80/80/70 (Typ.)(CR≥10)(L/R/U/D) |
| kekerapan | 60Hz |
| antara muka isyarat | LVDS (1 ch, 8-bit), 30 pins |
| voltan masukan | 12.0V (Typ.) |
| permohonan | LCTV |
| HT260WX1-100 | BOE | 26.0 | 1366×768 |
| HT260WX2-101 | BOE | 26.0 | 1366×768 |
| HT260WXC-100 | BOE | 26.0 | 1366×768 |
| LTA260AP02 | Samsung | 26.0 | 1366×768 |
| LTA260W2-L12 | Samsung | 26.0 | 1366×768 |
| T260XW01 V5 | AUO | 26.0 | 1280×768 |
| T260XW02 V0 | AUO | 26.0 | 1366×768 |
| T260XW04 V7 | AUO | 26.0 | 1366×768 |
| T260XW05 V0 | AUO | 26.0 | 1366×768 |
| V260B1-L11 | Innolux | 26.0 | 1366×768 |
| LC650EQD-FGF4 | LG Display | 65 | 3840×2160 |
| LTA216AT01 | Samsung | 21.6 | 1366×768 |
| LTA400WT-L09 | Samsung | 40 | 1366×768 |
| LTY460HS-LH2 | Samsung | 46 | 1920×1080 |
| T315HW05 V2 | AUO | 31.5 | 1920×1080 |
| T370XW02 VG | AUO | 37 | 1366×768 |
| T500HVN04.6 | AUO | 50 | 1920×1080 |
| V260B1-L02 | Innolux | 26.0 | 1366×768 |
| V315B3-L04 | Innolux | 31.5 | 1366×768 |
| V320BJ2-P01 | Innolux | 31.5 | 1366×768 |
