| Nombor Bahagian | LSC550HN06-W |
| Jenama | SAMSUNG |
| Saiz | 55 |
| Permohonan | TV Sets |
| Resolusi | 1920×1080 |
| Komposisi | a-Si TFT-LCD , CELL |
| Kecerahan | |
| CR | 5000:1 |
| Warna | 1.07B |
| Lampu latar | No |
| Antara muka | LVDS |
| jenama | SAMSUNG |
| saiz pepenjuru | 55 inch |
| format piksel | 1920(RGB)×1080 [FHD] 40PPI |
| kawasan aktif | 1209.6(H)×680.4(V) mm |
| kawasan bezel | - |
| kecerahan | 0 cd/m² |
| arah pandang | Symmetry |
| sudut pandangan | 89/89/89/89 (Typ.)(CR≥10) |
| ketebalan plat | 0.40+0.50 mm |
| warna sokongan | 1.07B 99% sRGB |
| berat badan | 2.33Kgs (Typ.) |
| kadar bingkai | 60Hz |
| perincian d-ic | COF Built-in 6 source chips |
| jenis antara muka | LVDS (2 ch, 10-bit) , 51 pins Connector |
| bekalan kuasa | 12.0V (Typ.) |
| persekitaran | Operating Temperature: 0 ~ 50 °C ; Storage Temperature: -20 ~ 65 °C |
| model | LSC550HN06-W |
| menaip | a-Si TFT-LCD , CELL |
| konfigurasi | RGB Vertical Stripe |
| garis besar malap. | 1219.6(H)×692.9(V) ×1.3(D) mm |
| rawatan | Antiglare (Haze 2.3%), Hard coating (2H) |
| nisbah kontras | 5000:1 (Typ.) (TM) |
| masa tindak balas | 6 (Typ.)(G to G) |
| mod operasi | SVA, Normally Black, Transmissive |
| penghantaran | 7.0% (Typ.)(with Polarizer) |
| sumber cahaya | No B/L |
| direka untuk | TV Sets |
| panel sentuh | Without |
