LC550EUD-SEF3

LC550EUD-SEF3
LC550EUD-SEF3
LC550EUD-SEF3 thumb LC550EUD-SEF3 thumb
Jenama
LG Display
Saiz
55
Permohonan
LCTV
Resolusi
1920×1080
Komposisi
LCM
Kecerahan
400
CR
1600:1
Warna
16.7M/1.06B
Lampu latar
WLED
Antara muka
LVDS
In Stock
8016
Spesifikasi

Nombor Bahagian LC550EUD-SEF3
JenamaLG Display
Saiz55
PermohonanLCTV
Resolusi1920×1080
KomposisiLCM
Kecerahan400
CR1600:1
Warna16.7M/1.06B
Lampu latarWLED
Antara mukaLVDS
jenama panelLG Display
model panelLC550EUD-SEF3
jenis panel a-Si TFT-LCD , LCM
saiz panel55 inch
resolusi1920(RGB)×1080 , FHD
mod paparanS-IPS, Normally Black, Transmissive
kawasan aktif1209.6×680.4 mm
garis besar1244.6×720.9 mm
permukaanAntiglare (Haze 1%), Hard coating (2H)
kecerahan400 cd/m² (Typ.)
nisbah kontras1600:1 (Typ.)
warna paparan16.7M/1.06B (8-bit / 8-bit + Dithering), CIE193172%
masa tindak balas5 (Typ.)(G to G); 8 (Typ.)(MPRT)
sudut pandangan89/89/89/89 (Min.)(CR≥10)(L/R/U/D)
kekerapan120Hz+120Hz
jenis lampuWLEDEmbedded (LED Driver)
antara muka isyaratLVDS (4 ch, 8/10-bit), 92 pins
voltan masukan12.0V (Typ.)
permohonanLCTV
