| Nombor Bahagian | LQ10PX01 |
| Jenama | SHARP |
| Saiz | 10.4 |
| Permohonan | PRO |
| Resolusi | 1024×768 |
| Komposisi | LCM |
| Kecerahan | 0 |
| CR | 60:1 |
| Warna | 262K |
| Lampu latar | No B/L |
| Antara muka | TTL |
| jenama panel | SHARP |
| model panel | LQ10PX01 |
| jenis panel | a-Si TFT-LCD , LCM |
| saiz panel | 10.4 inch |
| resolusi | 1024(RGB)×768 , XGA |
| mod paparan | TN, Normally White, Transmissive |
| kawasan aktif | 211.968×158.976 mm |
| garis besar | 283×215.6 mm |
| permukaan | |
| kecerahan | 0 cd/m² |
| nisbah kontras | 60:1 (Min.) |
| warna paparan | 262K (6-bit) |
| masa tindak balas | 30/50 (Typ.)(Tr/Td) |
| sudut pandangan | 45/45/30/10 (Typ.)(CR≥10)(L/R/U/D) |
| kekerapan | 60Hz |
| jenis lampu | No B/L |
| antara muka isyarat | Parallel RGB (1 ch, 6-bit), 36 pins |
| voltan masukan | 5.0/12.0V (Typ.)(VCC/VDD) |
| permohonan | PRO |
