| Nombor Bahagian | AT070TN01 |
| Jenama | Innolux |
| Saiz | 7.0 |
| Permohonan | DPF |
| Resolusi | 480×234 |
| Komposisi | LCM |
| Kecerahan | 350 |
| CR | 300:1 |
| Warna | Full color |
| Lampu latar | CCFL |
| Antara muka | Analog |
| jenama panel | INNOLUX |
| model panel | AT070TN01 |
| jenis panel | a-Si TFT-LCD , LCM |
| saiz panel | 7.0 inch |
| resolusi | 480(RGB)×234 |
| mod paparan | TN, Normally White, Transmissive |
| kawasan aktif | 154.08×86.58 mm |
| garis besar | 164.9×100×6 mm |
| permukaan | Antiglare |
| kecerahan | 350 cd/m² (Typ.) |
| nisbah kontras | 300:1 (Typ.) |
| warna paparan | Full color |
| masa tindak balas | 15/20 (Typ.)(Tr/Td) |
| sudut pandangan | 60/60/40/60 (Typ.)(CR≥10)(L/R/U/D) |
| kekerapan | 60Hz |
| jenis lampu | 1 pcsCCFLWithout Driver |
| antara muka isyarat | TFT Specific Analog RGB, 26 pins |
| voltan masukan | 5.0/5.0/15.0/-10.0 (Typ.)(VCC/AVDD/VGH/VGL) |
| permohonan | DPF |
