| Nombor Bahagian | LQ070Y3DG01 |
| Jenama | SHARP |
| Saiz | 7.0 |
| Permohonan | DPF |
| Resolusi | 800×480 |
| Komposisi | LCM |
| Kecerahan | 380 |
| CR | 350:1 |
| Warna | 262K |
| Lampu latar | CCFL |
| Antara muka | TTL |
| jenama panel | SHARP |
| model panel | LQ070Y3DG01 |
| jenis panel | a-Si TFT-LCD , LCM |
| saiz panel | 7.0 inch |
| resolusi | 800(RGB)×480 , WVGA |
| mod paparan | Transmissive |
| kawasan aktif | 152.4×91.44 mm |
| garis besar | 175×111.5×13.8 mm |
| permukaan | |
| kecerahan | 380 cd/m² (Typ.) |
| nisbah kontras | 350:1 (Typ.) |
| warna paparan | 262K (6-bit) |
| masa tindak balas | 10/15 (Typ.)(Tr/Td) |
| sudut pandangan | 60/60/50/60 (Typ.)(CR≥10)(L/R/U/D) |
| kekerapan | 60Hz |
| jenis lampu | 1 pcsCCFLWithout Driver |
| antara muka isyarat | CMOS (1 ch, 6-bit), 32 pins |
| voltan masukan | 5.0V (Typ.) |
| permohonan | DPF |
