| Nombor Bahagian | LQ057Q3DC02 |
| Jenama | SHARP |
| Saiz | 5.7 |
| Permohonan | IA |
| Resolusi | 320×240 |
| Komposisi | LCM |
| Kecerahan | 350 |
| CR | 60:1 |
| Warna | 262K |
| Lampu latar | CCFL |
| Antara muka | TTL |
| jenama panel | SHARP |
| model panel | LQ057Q3DC02 |
| jenis panel | a-Si TFT-LCD , LCM |
| saiz panel | 5.7 inch |
| resolusi | 320(RGB)×240 , QVGA |
| mod paparan | TN, Normally White, Transmissive |
| kawasan aktif | 115.2×86.4 mm |
| garis besar | 144×104.6×13.5 mm |
| permukaan | Hard coating (3H), Antireflection |
| kecerahan | 350 cd/m² (Typ.) |
| nisbah kontras | 60:1 (Min.) |
| warna paparan | 262K (6-bit) |
| masa tindak balas | 30/50 (Typ.)(Tr/Td) |
| sudut pandangan | 65/65/65/40 (Typ.)(CR≥5)(L/R/U/D) |
| jenis lampu | 1 pcsCCFLWithout Driver |
| antara muka isyarat | Parallel RGB (1 ch, 6-bit), 33 pins |
| voltan masukan | 3.3V (Typ.)(VCC) |
| permohonan | IA |
| DLC0570BDG-3 | Other | 5.7 | 640×480 |
| LM32004 | SHARP | 5.7 | 320×240 |
| LQ057AC111 | Other | 5.7 | 320×240 |
| LQ057Q3DC02 | SHARP | 5.7 | 320×240 |
| LQ057Q3DC03 | SHARP | 5.7 | 320×240 |
| LQ057Q3DC12 | SHARP | 5.7 | 320×240 |
| LQ057Q3DG02 | SHARP | 5.7 | 320×240 |
| LQ057V3DG01 | SHARP | 5.7 | 640×480 |
| LQ057V3DG02 | SHARP | 5.7 | 640×480 |
| LQ057V3LG11 | SHARP | 5.7 | 640×480 |
| AA141TC01 | Mitsubishi | 14.1 | 1280×800 |
| CLAA057VA02CW | CPT | 5.7 | 640×480 |
| KCS057QV1AJ-G23 | Kyocera | 5.7 | 320×240 |
| LB121S03-TL03 | LG Display | 12.1 | 800×600 |
| LM64P83L | SHARP | 9.4 | 640×480 |
| LM8V311 | SHARP | 7.7 | 640×480 |
| MAA121DSK26 | Mitsubishi | 12.1 | 800×600 |
| MC57T04L | Other | 5.7 | 320×240 |
| TFD50W72MS | TOSHIBA | 5.0 | |
| TM057QVHG01 | Tianma | 5.7 | 640×480 |
