| Nombor Bahagian | LM8V311 |
| Jenama | SHARP |
| Saiz | 7.7 |
| Permohonan | IA |
| Resolusi | 640×480 |
| Komposisi | LCM |
| Kecerahan | 55 |
| CR | 30:1 |
| Warna | Color |
| Lampu latar | CCFL |
| Antara muka | Parallel Data |
| jenama panel | SHARP |
| model panel | LM8V311 |
| jenis panel | CSTN-LCD , LCM |
| saiz panel | 7.7 inch |
| resolusi | 640(RGB)×480 , VGA |
| mod paparan | STN, Normally Black, Transmissive |
| kawasan aktif | 157.42×118.06 mm |
| garis besar | 197×142.5 mm |
| permukaan | |
| kecerahan | 55 cd/m² (Typ.) |
| nisbah kontras | 30:1 (Typ.) |
| warna paparan | Color |
| masa tindak balas | 270/80 (Typ.)(Tr/Td) |
| sudut pandangan | 30/30/15/30 (Typ.)(CR≥5)(L/R/U/D) |
| kekerapan | 75Hz |
| jenis lampu | 1 pcsCCFLWithout Driver |
| antara muka isyarat | Parallel Data (8-bit), 29 pins |
| voltan masukan | 3.3V (Typ.) |
| permohonan | IA |
