| Nombor Bahagian | LM12S49 |
| Jenama | SHARP |
| Saiz | 12.1 |
| Permohonan | IA |
| Resolusi | 800×600 |
| Komposisi | LCM |
| Kecerahan | 185 |
| CR | 40:1 |
| Warna | Color |
| Lampu latar | CCFL |
| Antara muka | TTL |
| jenama panel | SHARP |
| model panel | LM12S49 |
| jenis panel | CSTN-LCD , LCM |
| saiz panel | 12.1 inch |
| resolusi | 800(RGB)×600 , SVGA |
| mod paparan | STN, Normally Black, Transmissive |
| kawasan aktif | 246×184.5 mm |
| garis besar | 275×202.5×8.5 mm |
| permukaan | |
| kecerahan | 185 cd/m² (Typ.) |
| nisbah kontras | 40:1 (Typ.) |
| warna paparan | Color |
| masa tindak balas | 220/80 (Typ.)(Tr/Td) |
| sudut pandangan | 30/30/15/25 (Typ.)(CR≥5)(L/R/U/D) |
| kekerapan | 120Hz |
| jenis lampu | 2 pcsCCFLWithout Driver |
| antara muka isyarat | CMOS/TTL (1 ch, 8-bit), 41 pins |
| voltan masukan | 3.3/5.0V (Typ.)(VDD) |
| permohonan | IA |
