LC320WXD-SAC1

LC320WXD-SAC1
LC320WXD-SAC1 thumb
Jenama
LG Display
Saiz
31.5
Permohonan
LCTV
Resolusi
1366×768
Komposisi
LCM
Kecerahan
500
CR
1100:1
Warna
16.7M/1.07B
Lampu latar
EEFL
Antara muka
LVDS
In Stock
7728
Spesifikasi

Nombor Bahagian LC320WXD-SAC1
JenamaLG Display
Saiz31.5
PermohonanLCTV
Resolusi1366×768
KomposisiLCM
Kecerahan500
CR1100:1
Warna16.7M/1.07B
Lampu latarEEFL
Antara mukaLVDS
jenama panelLG.Philips LCD
model panelLC320WXD-SAC1
jenis panel a-Si TFT-LCD , LCM
saiz panel31.5 inch
resolusi1366(RGB)×768 , WXGA
mod paparanS-IPS, Normally Black, Transmissive
kawasan aktif697.685×392.256 mm
garis besar760×450×49 mm
permukaanAntiglare (Haze 13%), Hard coating (3H)
kecerahan500 cd/m² (Typ.)
nisbah kontras1100:1 (Typ.)
warna paparan16.7M/1.07B (8-bit / 8-bit + Hi-FRC)
masa tindak balas8 (Typ.)(G to G); 11 (Typ.)(MPRT)
sudut pandangan89/89/89/89 (Min.)(CR≥10)(L/R/U/D)
kekerapan120Hz (60Hz Input)
jenis lampu12 pcsEEFLEmbedded (Inverter)
antara muka isyaratLVDS (2 ch, 8/10-bit), 51 pins
voltan masukan12.0V (Typ.)
permohonanLCTV
