LC320WX6-SLA3

LC320WX6-SLA3
LC320WX6-SLA3
LC320WX6-SLA3 thumb LC320WX6-SLA3 thumb
Jenama
LG Display
Saiz
31.5
Permohonan
LCTV
Resolusi
1366×768
Komposisi
LCM
Kecerahan
500
CR
1000:1
Warna
16.7M
Lampu latar
EEFL
Antara muka
LVDS
In Stock
15570
Spesifikasi

Nombor Bahagian LC320WX6-SLA3
JenamaLG Display
Saiz31.5
PermohonanLCTV
Resolusi1366×768
KomposisiLCM
Kecerahan500
CR1000:1
Warna16.7M
Lampu latarEEFL
Antara mukaLVDS
jenama panelLG.Philips LCD
model panelLC320WX6-SLA3
jenis panel a-Si TFT-LCD , LCM
saiz panel31.5 inch
resolusi1366(RGB)×768 , WXGA
mod paparanS-IPS, Normally Black, Transmissive
kawasan aktif697.685×392.256 mm
garis besar760×450 mm
permukaanAntiglare (Haze 13%), Hard coating (3H)
kecerahan500 cd/m² (Typ.)
nisbah kontras1000:1 (Typ.)
warna paparan16.7M (8-bit)
masa tindak balas8/10 (Typ.)(Tr/Td)
sudut pandangan89/89/89/89 (Min.)(CR≥10)(L/R/U/D)
kekerapan60Hz
jenis lampu14 pcsEEFLWithout Driver
antara muka isyaratLVDS (1 ch, 8-bit), 30 pins
voltan masukan12.0V (Typ.)
permohonanLCTV
Model Keluarga
LC320W01-SL01 LG Display 31.5 1366×768
LC320W01-SLA1 LG Display 31.5 1366×768
LC320WUD-SBM2 LG Display 31.5 1920×1080
LC320WUG-SCA1 LG Display 31.5 1920×1080
LC320WUN-SBG3 LG Display 31.5 1920×1080
LC320WUN-SCB1 LG Display 31.5 1920×1080
LC320WXE-SCB1 LG Display 31.5 1366×768
LC320WXN-SAC2 LG Display 31.5 1366×768
LC320WXN-SCB1 LG Display 31.5 1366×768
LC320WXN-SCG1 LG Display 31.5 1366×768
