LC320DUE-FGA4

LC320DUE-FGA4
LC320DUE-FGA4
LC320DUE-FGA4 thumb LC320DUE-FGA4 thumb
Jenama
LG Display
Saiz
31.5
Permohonan
LCTV
Resolusi
1920×1080
Komposisi
LCM
Kecerahan
300
CR
1200:1
Warna
16.7M
Lampu latar
WLED
Antara muka
LVDS
In Stock
5110
Spesifikasi

Nombor Bahagian LC320DUE-FGA4
JenamaLG Display
Saiz31.5
PermohonanLCTV
Resolusi1920×1080
KomposisiLCM
Kecerahan300
CR1200:1
Warna16.7M
Lampu latarWLED
Antara mukaLVDS
jenama panelLG Display
model panelLC320DUE-FGA4
jenis panel a-Si TFT-LCD , LCM
saiz panel31.5 inch
resolusi1920(RGB)×1080 , FHD
mod paparanIPS, Normally Black, Transmissive
kawasan aktif698.4×392.85 mm
garis besar730.94×429.84×42 mm
permukaanAntiglare (Haze 1%), Hard coating (3H)
kecerahan300 cd/m² (Typ.)
nisbah kontras1200:1 (Typ.)
warna paparan16.7M (8-bit), CIE193166%
masa tindak balas7 (Typ.)(G to G)
sudut pandangan89/89/89/89 (Min.)(CR≥10)(L/R/U/D)
kekerapan60Hz
jenis lampuWLEDWithout Driver
antara muka isyaratLVDS (2 ch, 8-bit), 51 pins
voltan masukan12.0V (Typ.)
permohonanLCTV
Model Keluarga
LC320DUE-FGA4 LG Display 31.5 1920×1080
LC320DUH-FGP2 LG Display 31.5 1920×1080
LC320DUN-SFR1 LG Display 31.5 1920×1080
LC320DXJ-SFA9 LG Display 31.5 1366×768
LC320DXJ-SFE1 LG Display 31.5 1366×768
LC320DXJ-SFK1 LG Display 31.5 1366×768
LC320DXN-SER2 LG Display 31.5 1366×768
LC320DXN-SER3 LG Display 31.5 1366×768
LC320DXN-SEU1 LG Display 31.5 1366×768
LC320DXY-SGA2 LG Display 31.5 1366×768
