| Nombor Bahagian | KCG057QV1DC-G00 |
| Jenama | Kyocera |
| Saiz | 5.7 |
| Permohonan | Industrial |
| Resolusi | 320×240 |
| Komposisi | CSTN-LCD , LCM |
| Kecerahan | |
| CR | 55:1 |
| Warna | Color |
| Lampu latar | CCFL |
| Antara muka | |
| jenama panel | Kyocera |
| saiz panel | 5.7" |
| resolusi | 320(RGB)×240, QVGA, 70PPI |
| kawasan paparan | 115.2(W)×86.4(H) mm |
| kecerahan | - |
| sudut pandangan | 50/50/20/35 (Typ.)(CR≥2) |
| pandangan terbaik pada | - |
| warna paparan | Color |
| berat badan | - |
| model panel | KCG057QV1DC-G00 |
| jenis panel | CSTN-LCD , LCM |
| format piksel | RGB Vertical Stripe |
| pembukaan bezel | - |
| nisbah kontras | 55:1 (Typ.) (TM) |
| mod paparan | STN, Normally Black, Transmissive |
| masa tindak balas | 180/170 (Typ.)(Tr/Td) |
| jenis lampu | CCFL |
| permohonan | Industrial |
| EL320.240.36 HB | Lumineq | 5.7 | 320×240 |
| EW32F10BCW | EDT | 5.7 | 320×240 |
| G057VN01 V1 | AUO | 5.7 | 640×480 |
| KCG057QV1DB-G00 | Kyocera | 5.7 | 320×240 |
| KCG057QV1DB-G500 | Kyocera | 5.7 | 320×240 |
| KCG057QV1DB-G56 | Kyocera | 5.7 | 320×240 |
| KCG057QV1DB-G760 | Kyocera | 5.7 | 320×240 |
| KCG057QV1DB-G77 | Kyocera | 5.7 | 320×240 |
| LQ057Q3DC12 | SHARP | 5.7 | 320×240 |
| TM057KDH03 | Tianma | 5.7 | 320×240 |
