| Nombor Bahagian | HVA37WV1-D01 |
| Jenama | HYDIS |
| Saiz | 3.7 |
| Permohonan | MPH |
| Resolusi | 480×800 |
| Komposisi | CELL |
| Kecerahan | 0 |
| CR | 800:1 |
| Warna | |
| Lampu latar | No B/L |
| Antara muka | |
| jenama panel | HYDIS |
| model panel | HVA37WV1-D01 |
| jenis panel | a-Si TFT-LCD , CELL |
| saiz panel | 3.7 inch |
| resolusi | 480(RGB)×800 , WVGA |
| mod paparan | HFFS, Normally Black, Transmissive |
| kawasan aktif | 48.22×80.4 mm |
| garis besar | 51.84×88×0.5 mm |
| permukaan | Without Polarizer |
| kedalaman kaca | 0.25+0.25 mm |
| ketransmisian | 3.2% (Typ.)(with Polarizer) |
| nisbah kontras | 800:1 (Typ.) |
| warna paparan | |
| masa tindak balas | 40 (Typ.)(Tr+Td) |
| sudut pandangan | 89/89/89/89 (Typ.)(CR≥10)(L/R/U/D) |
| ic pemandu | Suggest LG4572, LG4573 |
| permohonan | MPH |
