Nombor Bahagian | LTA216AT01 |
Jenama | Samsung |
Saiz | 21.6 |
Permohonan | LCTV |
Resolusi | 1366×768 |
Komposisi | LCM |
Kecerahan | 350 |
CR | 800:1 |
Warna | 16.7M |
Lampu latar | CCFL |
Antara muka | LVDS |
jenama panel | SAMSUNG |
model panel | LTA216AT01 |
jenis panel | a-Si TFT-LCD , LCM |
saiz panel | 21.6 inch |
resolusi | 1366(RGB)×768 , WXGA |
mod paparan | TN, Normally White, Transmissive |
kawasan aktif | 477.417×268.416 mm |
garis besar | 501×297 mm |
permukaan | Hard coating (3H) |
kecerahan | 350 cd/m² (Typ.) |
nisbah kontras | 800:1 (Typ.) |
warna paparan | 16.7M (6-bit + Hi-FRC), CIE193172% |
masa tindak balas | |
sudut pandangan | 80/80/80/80 (Typ.)(CR≥10)(L/R/U/D) |
kekerapan | 60Hz |
jenis lampu | 4 pcsCCFLWithout Driver |
antara muka isyarat | LVDS (1 ch, 8-bit), 30 pins |
voltan masukan | 5.0V (Typ.) |
permohonan | LCTV |
