| Nombor Bahagian | HT260WX1-100 |
| Jenama | BOE |
| Saiz | 26.0 |
| Permohonan | LCTV |
| Resolusi | 1366×768 |
| Komposisi | LCM |
| Kecerahan | 450 |
| CR | 800:1 |
| Warna | 16.2M |
| Lampu latar | CCFL |
| Antara muka | LVDS |
| jenama panel | BOE |
| model panel | HT260WX1-100 |
| jenis panel | a-Si TFT-LCD , LCM |
| saiz panel | 26.0 inch |
| resolusi | 1366(RGB)×768 , WXGA |
| mod paparan | TN, Normally White, Transmissive |
| kawasan aktif | 575.769×323.712 mm |
| garis besar | 626×373×43.5 mm |
| permukaan | Antiglare (Haze 25%), Hard coating (3H) |
| kecerahan | 450 cd/m² (Typ.) |
| nisbah kontras | 800:1 (Typ.) |
| warna paparan | 16.2M (6-bit + FRC) |
| masa tindak balas | 5 (Typ.)(G to G) |
| sudut pandangan | 80/80/80/70 (Typ.)(CR≥10)(L/R/U/D) |
| kekerapan | 60Hz |
| jenis lampu | 4 pcsCCFLWithout Driver |
| antara muka isyarat | LVDS (1 ch, 8-bit), 30 pins |
| voltan masukan | 5.0V (Typ.) |
| permohonan | LCTV |
