| Nombor Bahagian | HT14P12-100 |
| Jenama | HYDIS |
| Saiz | 14.1 |
| Permohonan | NBPC |
| Resolusi | 1400×1050 |
| Komposisi | LCM |
| Kecerahan | 150 |
| CR | 200:1 |
| Warna | 262K |
| Lampu latar | CCFL |
| Antara muka | LVDS |
| jenama panel | BOE HYDIS |
| model panel | HT14P12-100 |
| jenis panel | a-Si TFT-LCD , LCM |
| saiz panel | 14.1 inch |
| resolusi | 1400(RGB)×1050 , SXGA+ |
| mod paparan | TN, Normally White, Transmissive |
| kawasan aktif | 285.6×214.2 mm |
| garis besar | 299×228×5.5 mm |
| gaya bentuk | Wedge (PCBA Bent, Depth ≥5.2mm) |
| permukaan | |
| kecerahan | 150 cd/m² (Typ.) |
| nisbah kontras | 200:1 (Min.) |
| warna paparan | 262K (6-bit) |
| masa tindak balas | 25/25 (Max.)(Tr/Td) |
| sudut pandangan | 45/45/15/35 (Typ.)(CR≥10)(L/R/U/D) |
| kekerapan | 60Hz |
| jenis lampu | 1 pcsCCFLWithout Driver |
| antara muka isyarat | LVDS (2 ch, 6-bit), 30 pins |
| voltan masukan | 3.3V (Typ.) |
| permohonan | NBPC |
