| Nombor Bahagian | GV101WXB-NZ1-DGP0 |
| Jenama | BOE |
| Saiz | 10.1 |
| Permohonan | Industrial |
| Resolusi | 1280×800 |
| Komposisi | CELL, a-Si TFT-LCD |
| Kecerahan | |
| CR | 1000:1 |
| Warna | 16.7M |
| Lampu latar | No |
| Antara muka | |
| pengilang | BOE |
| nama model | GV101WXB-NZ1-DGP0 |
| saiz skrin | 10.1 inch |
| jenis skrin | CELL, a-Si TFT-LCD |
| nombor piksel | 1280(RGB)×800 (WXGA) 149PPI |
| susunan | RGB Vertical Stripe |
| kawasan aktif (mm) | 216.96 × 135.6 (H×V) |
| garis besar (mm) | 221.96 × 144.43 × 1.06 (H×V×D) |
| kawasan bezel (mm) | - |
| rawatan | Without Polarizer, Hard coating |
| kecerahan | 0 cd/m² |
| nisbah kontras | 1000 : 1 (Typ.) (TM) |
| sudut pandangan | 80/80/80/80 (Typ.)(CR≥10) |
| tindak balas | 35 (Typ.)(Tr+Td) ms |
| pandangan yang baik di | Symmetry |
| mod kerja | ADS, Normally Black, Transmissive |
| kedalaman warna | 16.7M 50% NTSC |
| lampu latar | No B/L , With LED Driver |
| jisim | - |
| digunakan untuk | Industrial |
| kadar segar semula | 60Hz |
| skrin sentuh | Without |
| Storage Temp.: -30 ~ 80 °C Operating Temp.: -20 ~ 70 °C |
