| Nombor Bahagian | GT070WVM-N10-3GP0 |
| Jenama | BOE |
| Saiz | 7.0 |
| Permohonan | Industrial |
| Resolusi | 800×480 |
| Komposisi | a-Si TFT-LCD , LCM |
| Kecerahan | |
| CR | 600:1 |
| Warna | 262K/16.7M |
| Lampu latar | WLED |
| Antara muka | |
| jenama panel | BOE |
| saiz panel | 7.0" |
| resolusi | 800(RGB)×480, WVGA, 134PPI |
| kawasan paparan | 154.08(W)×85.92(H) mm |
| saiz garis besar | 164.9(W)×100(H) ×6(D) mm |
| kecerahan | 500 cd/m² (Typ.) |
| sudut pandangan | 75/75/60/75 (Typ.)(CR≥10) |
| pandangan terbaik pada | - |
| warna paparan | 262K/16.7M 50% NTSC |
| kekerapan | 60Hz |
| berat badan | 133±5g |
| model panel | GT070WVM-N10-3GP0 |
| jenis panel | a-Si TFT-LCD , LCM |
| format piksel | RGB Vertical Stripe |
| pembukaan bezel | 157.08(W)×89.33(H) mm |
| permukaan | Antiglare (Haze 25%), Hard coating (3H) |
| nisbah kontras | 600:1 (Typ.) (TM) |
| mod paparan | TN, Normally White, Transmissive |
| masa tindak balas | 25 (Typ.)(Tr+Td) |
| jenis lampu | WLED , Without Driver |
| skrin sentuh | Without |
| permohonan | Industrial |
| C070FW02 V2 | AUO | 7.0 | 480×234 |
| C070FW03 V0 | AUO | 7.0 | 480×234 |
| HJ070NA-13A | Innolux | 7.0 | 1024×600 |
| HV070WX2-100 | HYDIS | 7.0 | 800×1280 |
| LD070WS2-SL07 | LG Display | 7.0 | 1024×600 |
| LQ070T5BG01 | SHARP | 7.0 | 480×234 |
| LQ070Y3LG4A | SHARP | 7.0 | 800×480 |
| TD070WGCB2 | TPO | 7.0 | 854×480 |
| VVX07H005A90 | Panasonic | 7.0 | 800×1280 |
| YX070DK02 | SEBO | 7.0 | 800×480 |
