| Nombor Bahagian | G101EVT03.2 |
| Jenama | AUO |
| Saiz | 10.1 |
| Permohonan | Industrial |
| Resolusi | 1280×800 |
| Komposisi | LCM , a-Si TFT-LCD |
| Kecerahan | |
| CR | 1300:1 |
| Warna | 262K |
| Lampu latar | WLED |
| Antara muka | |
| pengilang | AUO |
| nama model | G101EVT03.2 |
| saiz skrin | 10.1 inch |
| jenis skrin | LCM , a-Si TFT-LCD |
| nombor piksel | 1280(RGB)×800 (WXGA) 149PPI |
| susunan | RGB Vertical Stripe |
| kawasan aktif (mm) | 216.96 × 135.6 (H×V) |
| garis besar (mm) | - |
| kecerahan | - |
| nisbah kontras | 1300 : 1 (Typ.) (TM) |
| sudut pandangan | 85/85/85/85 (Typ.)(CR≥10) |
| tindak balas | 25 (Typ.)(Tr+Td) ms |
| pandangan yang baik di | Symmetry |
| mod kerja | MVA, Normally Black, Transmissive |
| kedalaman warna | 262K 45% NTSC |
| lampu latar | WLED |
| jisim | - |
| digunakan untuk | Industrial |
| kadar segar semula | 60Hz |
| skrin sentuh | - |
| AM-1280800N1TZQW-T06H | AMPIRE | 10.1 | 1280×800 |
| AM-1280800N2TZQW-T48H | AMPIRE | 10.1 | 1280×800 |
| B101EAN02.2 | AUO | 10.1 | 800×1280 |
| CLAA101WA01A | CPT | 10.1 | 1366×768 |
| G101EVN01.0 | AUO | 10.1 | 1280×800 |
| G101EVN01.3 | AUO | 10.1 | 1280×800 |
| HSD100IFW3-A00 | HannStar | 10.1 | 1024×600 |
| HV101HD1-1E0 | HYDIS | 10.1 | 1366×768 |
| N101L6-L01 | Innolux | 10.1 | 1024×600 |
| VVX10F004B00 | Panasonic | 10.1 | 1920×1200 |
