| Nombor Bahagian | TM028HBHG02 |
| Jenama | Tianma |
| Saiz | 2.8 |
| Permohonan | MPH |
| Resolusi | 240×320 |
| Komposisi | LCM |
| Kecerahan | 210 |
| CR | 500:1 |
| Warna | 262K |
| Lampu latar | WLED |
| Antara muka | CPU |
| jenama panel | TIANMA |
| model panel | TM028HBHG02 |
| jenis panel | a-Si TFT-LCD , LCM |
| saiz panel | 2.8 inch |
| resolusi | 240(RGB)×320 , QVGA |
| mod paparan | TN, Normally White, Transmissive |
| kawasan aktif | 43.2×57.6 mm |
| garis besar | 50×69.2×4.4 mm |
| permukaan | Clear |
| kecerahan | 210 cd/m² (Typ.) |
| nisbah kontras | 500:1 (Typ.) |
| warna paparan | 262K (6-bit), CIE193165% |
| masa tindak balas | 20 (Typ.)(Tr+Td) |
| sudut pandangan | 70/70/70/60 (Typ.)(CR≥10)(L/R/U/D) |
| jenis lampu | 1S4PWLEDWithout Driver |
| antara muka isyarat | 8/16-bit 6080/8080 parallel, 37 pins |
| voltan masukan | (1.8/2.8)/2.8V (Typ.)(VCC/VCI) |
| permohonan | MPH |
