| Nombor Bahagian | DBT070CTV50R9 |
| Jenama | No Brand |
| Saiz | 7.0 |
| Permohonan | Industrial Outdoor H |
| Resolusi | 800×480 |
| Komposisi | a-Si TFT-LCD , LCM |
| Kecerahan | |
| CR | 500:1 |
| Warna | 16.7M |
| Lampu latar | WLED |
| Antara muka | |
| jenama | No Brand |
| saiz pepenjuru | 7.0 inch |
| format piksel | 800(RGB)×480 [WVGA] 134PPI |
| kawasan aktif | 154.08(H)×85.92(V) mm |
| kawasan bezel | 157(H)×89.5(V) mm |
| kecerahan | 1000 cd/m² (Typ.) |
| arah pandang | - |
| sudut pandangan | 70/70/50/70 (Typ.)(CR≥10) |
| warna sokongan | 16.7M |
| berat badan | TBD |
| kadar bingkai | 60Hz |
| model | DBT070CTV50R9 |
| menaip | a-Si TFT-LCD , LCM |
| konfigurasi | RGB Vertical Stripe |
| garis besar malap. | 165(H)×100(V) mm |
| rawatan | Antiglare |
| nisbah kontras | 500:1 (Typ.) (TM) |
| masa tindak balas | 10/15 (Typ.)(Tr/Td) |
| mod operasi | TN, Normally White, Transmissive |
| sumber cahaya | WLED , 20K hours , W/O Driver |
| direka untuk | Industrial Outdoor High Brightness |
| panel sentuh | Without |
