| Nombor Bahagian | CLAA123PA02CW |
| Jenama | CPT |
| Saiz | 12.3 |
| Permohonan | Industrial Outdoor H |
| Resolusi | 1440×540 |
| Komposisi | a-Si TFT-LCD, LCM |
| Kecerahan | |
| CR | 700:1 |
| Warna | 16.7M |
| Lampu latar | WLED |
| Antara muka | LVDS |
| jenama | CPT |
| model | CLAA123PA02CW |
| saiz pepenjuru | 12.3 inch |
| menaip | a-Si TFT-LCD, LCM |
| format piksel | 1440(RGB)×540 125PPI |
| konfigurasi | RGB Vertical Stripe |
| kawasan aktif | 291.6(H)×109.35(V) mm |
| garis besar malap. | 312.9(H)×132.2(V) ×19.2(D) mm |
| kawasan bezel | 294.8(H)×112.4(V) mm |
| rawatan | Antiglare (Haze 25%) |
| kecerahan | 800 cd/m² (Typ.) |
| nisbah kontras | 700:1 (Typ.) (TM) |
| arah pandang | 6 o'clock |
| masa tindak balas | 25 (Typ.)(Tr+Td) |
| sudut pandangan | 60/60/50/60 (Typ.)(CR≥10) |
| mod operasi | TN, Normally White, Transmissive |
| warna sokongan | 16.7M 70% NTSC |
| sumber cahaya | WLED [8S3P] , 30K hours , W/O Driver |
| berat badan | 510g (Typ.) |
| direka untuk | Industrial Outdoor High Brightness Automotive Display |
| kadar bingkai | 60Hz |
| panel sentuh | Without |
| jenis antara muka | LVDS (1 ch, 8-bit) , 30 pins Connector |
| bekalan kuasa | 3.3V (Typ.) |
| persekitaran | Operating Temperature: -40 ~ 85 °C ; Storage Temperature: -40 ~ 90 °C ; Vibration Level: 2.9G (28.4 m/s²) |
