| Nombor Bahagian | BTL282440-310L |
| Jenama | BOE |
| Saiz | 2.8 |
| Permohonan | MPH |
| Resolusi | 240×400 |
| Komposisi | LCM |
| Kecerahan | 190 |
| CR | 240:1 |
| Warna | 262K |
| Lampu latar | WLED |
| Antara muka | CPU |
| jenama panel | BOE |
| model panel | BTL282440-310L |
| jenis panel | a-Si TFT-LCD , LCM |
| saiz panel | 2.8 inch |
| resolusi | 240(RGB)×400 , WQVGA |
| mod paparan | TN, Normally White, Transmissive |
| kawasan aktif | 36.72×61.2 mm |
| garis besar | 42.5×71.4 mm |
| permukaan | Clear |
| kecerahan | 190 cd/m² (Typ.) |
| nisbah kontras | 240:1 (Typ.) |
| warna paparan | 262K |
| masa tindak balas | 25 (Typ.)(Tr+Td) |
| sudut pandangan | 55/55/60/30 (Typ.)(CR≥10)(L/R/U/D) |
| kekerapan | 60Hz |
| jenis lampu | 1S4PWLEDWithout Driver |
| antara muka isyarat | CPU, 31 pins |
| voltan masukan | 2.8/2.8V (Typ.)(IOVCC/VCC) |
| permohonan | MPH |
