| Nombor Bahagian | B079XAN01.0 |
| Jenama | AUO |
| Saiz | 7.9 |
| Permohonan | PAD |
| Resolusi | 768×1024 |
| Komposisi | LCM |
| Kecerahan | 400 |
| CR | 800:1 |
| Warna | 262K |
| Lampu latar | WLED |
| Antara muka | MIPI |
| jenama panel | AUO |
| model panel | B079XAN01.0 1 Compatible model |
| jenis panel | a-Si TFT-LCD , LCM |
| saiz panel | 7.9 inch |
| resolusi | 768(RGB)×1024 , XGA |
| mod paparan | AHVA, Normally Black, Transmissive |
| kawasan aktif | 119.808×159.744 mm |
| garis besar | 129×171.07×4.81 mm |
| permukaan | |
| kecerahan | 400 cd/m² (Typ.) |
| nisbah kontras | 800:1 (Typ.) |
| warna paparan | 262K (6-bit), CIE193150% |
| masa tindak balas | 25 (Typ.)(Tr+Td) |
| sudut pandangan | 89/89/89/89 (Typ.)(CR≥10)(L/R/U/D) |
| kekerapan | 60Hz |
| jenis lampu | 6 stringsWLEDWithout Driver |
| antara muka isyarat | MIPI (4 data lanes), 32 pins |
| voltan masukan | 3.3V (Typ.) |
| permohonan | PAD |
| B079XAN01.0 | AUO | 7.9 | 768×1024 |
| B101EW05 V1 | AUO | 10.1 | 1280×800 |
| B101UAN01.7 HW1A | AUO | 10.1 | 1920×1200 |
| BP101WX1-100 | BOE | 10.1 | 1280×800 |
| CLAA070WP06 XG | CPT | 7.0 | 800×1280 |
| HSD101PWW1-A00 Rev.4 | HannStar | 10.1 | 1280×800 |
| HSD101PWW2-A00 | HannStar | 10.1 | 1280×800 |
| LD070WU2-SH01 | LG Display | 7.0 | 1200×1920 |
| LP097X02-SLA3 | LG Display | 9.7 | 1024×768 |
| LTL070AL03 | Samsung | 7.0 | 800×1280 |
