| Nombor Bahagian | AV128HDM-NW0 |
| Jenama | BOE |
| Saiz | 12.8 |
| Permohonan | CNS |
| Resolusi | 1280×720 |
| Komposisi | LCM |
| Kecerahan | 500 |
| CR | 900:1 |
| Warna | 16.7M |
| Lampu latar | WLED |
| Antara muka | LVDS |
| jenama panel | BOE |
| model panel | AV128HDM-NW0 |
| jenis panel | a-Si TFT-LCD , LCM |
| saiz panel | 12.8 inch |
| resolusi | 1280(RGB)×720 , WXGA |
| mod paparan | ADS, Normally Black, Transmissive |
| kawasan aktif | 283.2×159.3 mm |
| garis besar | 300.8×179.5×8 mm |
| permukaan | |
| kecerahan | 500 cd/m² (Typ.) |
| nisbah kontras | 900:1 (Typ.) |
| warna paparan | 16.7M (8-bit), CIE193172% |
| masa tindak balas | 30 (Typ.)(Tr+Td) |
| sudut pandangan | 80/80/80/80 (Typ.)(CR≥10)(L/R/U/D) |
| kekerapan | 60Hz |
| jenis lampu | 4S10PWLEDWithout Driver |
| antara muka isyarat | LVDS (1 ch, 8-bit), 50 pins |
| voltan masukan | 3.3/11.5/22/-9V (Typ.)(VCC/AVDD/VGH/VGL) |
| permohonan | CNS |
