| Nombor Bahagian | AM-640480GSTMQW-00H-A |
| Jenama | AMPIRE |
| Saiz | 5.7 |
| Permohonan | Industrial |
| Resolusi | 640×480 |
| Komposisi | a-Si TFT-LCD , LCM |
| Kecerahan | |
| CR | 600:1 |
| Warna | 262K |
| Lampu latar | 3S7P |
| Antara muka | |
| jenama panel | AMPIRE |
| saiz panel | 5.7" |
| resolusi | 640(RGB)×480, VGA, 141PPI |
| kawasan paparan | 115.2(W)×86.4(H) mm |
| saiz garis besar | 144(W)×104.6(H) ×12.6(D) mm |
| kecerahan | 400 cd/m² (Typ.) |
| sudut pandangan | 75/75/65/65 (Typ.)(CR≥10) |
| pandangan terbaik pada | 6 o'clock |
| warna paparan | 262K 50% NTSC |
| kekerapan | 60Hz |
| berat badan | - |
| model panel | AM-640480GSTMQW-00H-A |
| jenis panel | a-Si TFT-LCD , LCM |
| format piksel | RGB Vertical Stripe |
| pembukaan bezel | 118.2(W)×89.4(H) mm |
| permukaan | Antiglare |
| nisbah kontras | 600:1 (Typ.) (TM) |
| mod paparan | TN, Normally White, Transmissive |
| masa tindak balas | 50 (Typ.)(Tr+Td) |
| jenis lampu | 3S7P WLED , 20K hours , With LED Driver |
| skrin sentuh | Without |
| permohonan | Industrial |
