| Nombor Bahagian | AM-640480GJTNQW-TA2H |
| Jenama | AMPIRE |
| Saiz | 5.7 |
| Permohonan | Industrial |
| Resolusi | 640×480 |
| Komposisi | a-Si TFT-LCD, LCM |
| Kecerahan | |
| CR | 250:1 |
| Warna | 262K |
| Lampu latar | WLED |
| Antara muka | LVDS |
| jenama panel | AMPIRE |
| model panel | AM-640480GJTNQW-TA2H |
| saiz panel | 5.7" |
| jenis panel | a-Si TFT-LCD, LCM |
| resolusi | 640(RGB)×480, VGA, 141PPI |
| format piksel | RGB Vertical Stripe |
| kawasan paparan | 115.2(W)×86.4(H) mm |
| pembukaan bezel | - |
| saiz garis besar | 127(W)×98.43(H) ×10.88(D) mm |
| permukaan | - |
| kecerahan | 425 cd/m² (Typ.) |
| nisbah kontras | 250:1 (Typ.) (TM) |
| sudut pandangan | 70/70/50/50 (Typ.)(CR≥10) |
| mod paparan | TN, Normally White, Transmissive |
| pandangan terbaik pada | - |
| masa tindak balas | 50 (Typ.)(Tr+Td) |
| warna paparan | 262K 50% NTSC |
| jenis lampu | WLED , 20K hours , With LED Driver |
| kekerapan | 60Hz |
| skrin sentuh | PCAP |
| berat panel | - |
| permohonan | Industrial |
| antara muka isyarat | LVDS (1 ch, 8-bit) , 20 pins Connector |
| voltan masukan | 3.3V (Typ.) |
| persekitaran | Operating Temp.: -20 ~ 70 °C ; Storage Temp.: -30 ~ 80 °C |
| AM-640480G2TNQW-00H-F | AMPIRE | 5.7 | 640×480 |
| AM-640480G2TNQW-31H | AMPIRE | 5.7 | 640×480 |
| AM-640480G2TNQW-31H-F | AMPIRE | 5.7 | 640×480 |
| AM-640480G2TNQW-T01H-A | AMPIRE | 5.7 | 640×480 |
| AM-640480G4TNQW-A0H | AMPIRE | 5.7 | 640×480 |
| AM-640480G4TNQW-T01H | AMPIRE | 5.7 | 640×480 |
| AM-640480GFTNQW-T01H-L | AMPIRE | 5.7 | 640×480 |
| AM-640480GJTNQW-TA0H | AMPIRE | 5.7 | 640×480 |
| G057VN01 V1 | AUO | 5.7 | 640×480 |
| TM057KDHG03 | Tianma | 5.7 | 320×240 |
